AODE’s portable air cooled chillers are engineered with energy-saving technologies, reducing operational costs while delivering consistent cooling performance.
Eco-friendly refrigerants comply with global environmental standards, offering both energy efficiency and sustainability.
The chillers are available in various cooling capacities, tailored to the specific needs of different industries. From light to heavy-duty applications, AODE offers models that can cool industrial machinery, commercial equipment, and process cooling with precision.
Cooling capacities range from small 5 Ton models to large 50 Ton units, suitable for different industrial scales.
These chillers feature a space-saving, portable design, enabling easy transportation and installation in tight spaces or locations with limited room for fixed units.
Designed for mobility, the portable units come with built-in wheels, making them easy to move between various industrial settings.
Tailored solutions are available, including different voltage options (e.g., 380V, 50Hz), and the ability to customize cooling capacities to fit specific cooling loads.
Users can select additional features such as digital temperature controllers, remote monitoring capabilities, and multiple outlet connections to suit their operational needs.
| Model | Cooling Capacity (kW/Ton) | Compressor Type | Refrigerant | Voltage Options | Pump Flow Rate (L/min) | Tank Capacity (L) | Operating Temperature Range (°C) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| AODE-PAC-5T | 17.5 kW / 5 Ton | Scroll | R410A/R407C | 220V/380V/50Hz | 100 L/min | 80 L | 5°C - 35°C | 180 |
| AODE-PAC-10T | 35 kW / 10 Ton | Scroll | R410A/R407C | 380V/50Hz | 200 L/min | 120 L | 5°C - 35°C | 320 |
| AODE-PAC-15T | 52.5 kW / 15 Ton | Scroll | R410A/R407C | 380V/50Hz | 300 L/min | 160 L | 5°C - 35°C | 450 |
| AODE-PAC-20T | 70 kW / 20 Ton | Scroll / Screw | R410A/R407C | 380V/50Hz | 400 L/min | 200 L | 5°C - 35°C | 620 |
| AODE-PAC-30T | 105 kW / 30 Ton | Screw | R134a/R407C | 380V/50Hz | 600 L/min | 300 L | 5°C - 35°C | 920 |
| AODE-PAC-50T | 175 kW / 50 Ton | Screw | R134a/R407C | 380V/50Hz | 1000 L/min | 500 L | 5°C - 35°C | 1500 |
| Specification | Details |
|---|---|
| Cooling Method | Air-cooled |
| Heat Exchanger Type | Finned Coil / Brazed Plate |
| Evaporator Material | Stainless Steel / Copper Tube |
| Condenser Type | Aluminum Fins & Copper Tubes |
| Control System | Digital Temperature Controller |
| Fan Type | Axial Fan / Variable Speed |
| Noise Level (dB) | 50-75 dB (varies by model) |
| Mobility | Heavy-duty caster wheels |
| Safety Features | Overload Protection, High/Low Pressure Switch, Flow Protection |
| Warranty | 12-24 months |
AODE Portable Air Cooled Chillers are ideal for a range of industries, including:
Injection molding and plastic manufacturing
Machinery cooling in industrial plants
HVAC systems for commercial buildings
Food and beverage production
Laboratories and medical applications requiring precise temperature control
Designed for low-maintenance operation, AODE’s chillers are equipped with durable components, reducing downtime and service costs.
Robust, corrosion-resistant materials are used in construction, ensuring long-term reliability even in harsh working conditions.
These chillers comply with global environmental regulations, including CE, ISO, and ROHS standards.
The use of environmentally friendly refrigerants ensures compliance with both local and international sustainability standards.
The price range for AODE’s portable air cooled chillers varies based on factors like cooling capacity, customization options, and additional features.
Standard models start at competitive prices for smaller applications, with larger, high-capacity models priced accordingly.
Operational cost factors include energy consumption, maintenance requirements, and the lifetime of the unit. AODE’s energy-efficient chillers provide an excellent ROI by reducing energy bills and minimizing maintenance costs.
Easy-to-use controls with clear digital displays allow users to quickly adjust settings, monitor performance, and track cooling processes.
Remote monitoring options are available, enabling businesses to manage their chillers more effectively, especially in large-scale operations or multiple locations.
Cooling efficiency: AODE chillers deliver superior cooling performance, providing a reliable cooling solution even in the most demanding applications.
Energy consumption: Reduced energy costs through innovative energy-saving technologies.
System reliability: AODE’s chillers are built to operate continuously with minimal downtime.
The Portable Air Cooled Chiller market is witnessing steady growth, driven by increasing demand for efficient, space-saving, and eco-friendly cooling solutions across industries such as manufacturing, HVAC, food processing, and more. With advancements in technology, portable chillers are becoming more energy-efficient, compact, and user-friendly, offering flexible solutions for temperature control in small spaces or temporary installations.
AODE's strategic focus is to enhance product innovation while maintaining a strong commitment to customization. Our chillers are equipped with the latest scroll and screw compressor technology, offering superior cooling capacity and energy savings. We prioritize environmentally friendly refrigerants like R410A and R407C and ensure that all models comply with global industry standards. Additionally, AODE’s focus on mobility and ease of installation ensures that our portable air cooled chillers can be deployed quickly and effectively in any setting.
AODE’s chillers come with multi-size options and configurations, making them suitable for varied industrial applications. The investment in these chillers guarantees high ROI due to their long lifespan, low maintenance requirements, and energy efficiency.
When selecting a portable air cooled chiller, focus on cooling capacity, refrigerant type, energy consumption, and mobility. Choose AODE for reliable performance, customization, and durability, backed by excellent customer service.
