Product Details:
| Place of Origin: | Industrial Chiller Supplier |
| Brand Name: | AODE |
| Certification: | ISO, CE, ROHS |
| Model Number: | AC-330AS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $ |
| Packaging Details: | Protective/air bubble film, Wooden case. As client’s require |
| Delivery Time: | Within 20days after receiving |
| Payment Terms: | 30% T/T in advance, 70% balanc |
| Supply Ability: | 500pcs/month |
Water To Water Chiller, Low Temperature Water To Water Chiller, 283,800 Kcal/h Water To Water Chiller, Water To Water Chiller With ISO & CE Certified made from our AODE's industrial chiller factory are high quality, we provide high quality Low Temperature Water To Water Chiller 283800 Kcal/h Cooling With ISO & CE Certified for sale from China.
Low Temperature Water To Water Chiller 283800 Kcal/h is a high-performance cooling solution with a refrigerating capacity of 283,800 Kcal/h, ensuring efficient temperature control between 7-35℃ with ±2℃ precision. Equipped with a semi-enclosed screw-type compressor, it operates with maximum reliability and energy savings, reducing power consumption by over 30%. The chiller includes a high-efficiency shell and tube evaporator and copper coil condenser with aluminum fins, ensuring optimal heat exchange performance. Certified by ISO & CE, it features advanced safety protections, including high/low pressure switches, overload protection, and an anti-frost protector. The RS485 communication function (optional) allows for remote automation, making it ideal for die casting, printing, and extruder applications.
| Product Name: | Water to water chiller | Brand Name: | AODE |
|---|---|---|---|
| Application: | Die Casting|Pringting|Extruder | Certification: | CE|ISO |
| Compressor Type: | Semi-enclosed Screw-type | Dimension: | 2260*2260*2390mm |
| Power Supply: | 3N-50HZ-380V | Temperature Range: | 7-35℃ |
| Theory: | Air Cooled | ||
| High Light: | Water To Water Chiller, Low Temperature Water To Water Chiller, 283800 Kcal/h Water To Water Chiller, Water To Water Chiller With ISO CE Certified | ||
ITEM | UNIT | AC-330AS | |
Refrigerating capacity | Kcal/h | 283800 | |
KW | 330 | ||
Power Input | KW | 117 | |
Maximum Running Current | A | 197.5 | |
Energy adjust range | % | 100-75-50-25-0 | |
Power supply | 3N-50HZ-380V | ||
R22 Refrigerant | Filling Volume | kg | 86 |
Control mode | Thermostatic Expansion valve | ||
Compressor | Model | Screw semi-hermetic | |
Power | Kw | 111 | |
Condenser | Copper Coil With Aluminium Fine | ||
Fan | Type | Low Noise Aluminium Blade Axial Fa | |
Air Flow | M3/h | 115000 | |
Evaporator | Model | Shell and Tube | |
Chilled water flow | M3/h | 56.8 | |
Water resistance | Kpa | 45 | |
Water inlet/outlet diameter | DN | 100.0 | |
Protecting equipment | High/Low Pressure switch, Anti-frost Protector, Fusible Plug, Overload Protector, Motor Overheat Protector, Automatic Temperature Sensitive Switch, Anti-phase Protector | ||
Size(L×W×H) | mm | 2260×2260×2390 | |
Weight | kg | 2500 | |
Running Weight | Kg | 2640 | |
High Cooling Capacity – 283,800 Kcal/h, perfect for industrial-scale cooling applications.
Energy Efficient – Saves over 30% energy with high-performance evaporator and condenser.
Advanced Safety System – Includes high/low pressure protection, overload, and anti-frost protection.
Smart Control – Microcomputer or optional PLC control for automated operation.
Durable Build – Stainless steel plate, shell and tube heat exchanger for long-term use.
Remote Monitoring – RS485 communication function (optional) for automated management.
Reliable Cooling Performance: Stable temperature control between 7-35℃ with ±2℃ precision.
Powerful Compressor: Semi-hermetic screw-type compressor for consistent and efficient cooling.
Large Airflow & High Heat Exchange Efficiency: 115,000 m³/h air flow rate for rapid cooling.
Comprehensive Safety Features: Includes fusible plug, motor overheat protection, and anti-phase protector.
Flexible Energy Adjustment: 100-75-50-25-0% energy regulation for adaptable power consumption.
Certified & Compliant: Meets ISO & CE certification standards for industrial-grade quality.
For industries requiring stable and precise cooling, such as die casting, printing, and extrusion.
When energy efficiency is a priority, as it reduces operational costs by over 30%.
For automated processes, with optional PLC & RS485 communication for remote control.
For operations with strict safety requirements, thanks to comprehensive protection features.
When dealing with high heat loads, needing a powerful 330 kW cooling capacity.
Control System Options – Choose between microcomputer or PLC control for advanced automation.
Refrigerant Choice – Default R22, but other refrigerants can be customized.
Condenser Material – Aluminum fins or stainless steel options available.
Power Supply Adaptation – Can be tailored to regional voltage requirements.
Cooling Capacity Adjustments – Custom designs available for different cooling needs.
Base Price: Varies based on configuration, if you are interesting, you can contactu s to confirm.
Factors Affecting Price:
Compressor type & efficiency level
Control system (microcomputer vs. PLC automation)
Customization of refrigerant & condenser materials
Installation & shipping costs based on location
What is the cooling capacity of this water-to-water chiller?
It delivers 283,800 Kcal/h (330 kW), making it suitable for industrial-scale cooling applications.
What industries use this chiller?
Ideal for die casting, printing, extruder cooling, and other manufacturing processes that require precise temperature control.
Does it come with a remote control function?
Yes, RS485 communication is available as an option for automated management.
What is the energy efficiency of this unit?
It reduces energy consumption by over 30%, thanks to its high-efficiency evaporator and condenser.
What protection systems are included?
Equipped with high/low pressure switches, overload protection, fusible plug, motor overheat protection, and anti-frost protector.
What are the installation requirements?
It requires a stable 3N-50HZ-380V power supply, proper ventilation, and regular maintenance for optimal performance.
