Product Details:
| Place of Origin: | Industrial Chiller Supplier |
| Brand Name: | AODE |
| Certification: | ISO, CE, ROHS |
| Model Number: | AC-35WD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $ |
| Packaging Details: | Protective/air bubble film, Wooden case. As client’s require |
| Delivery Time: | Within 20days after receiving |
| Payment Terms: | 30% T/T in advance, 70% balanc |
| Supply Ability: | 500pcs/month |
This Water Cooled Chiller AC-35WT is designed to deliver outstanding performance in industrial cooling applications such as plastic injection molding and die casting. Featuring high cooling capacity, robust construction, and advanced safety features, this chiller ensures optimal performance and energy savings. With a powerful compressor and a high-flow cooling system, it guarantees efficient and reliable temperature control for demanding environments.
| Product Name: | Water Cooled Chiller | Brand Name: | AODE |
|---|---|---|---|
| Application: | Die Casting|Plastic Injection Molding | Certification: | CE|ISO |
| Compressor Type: | Hermetic Scroll Or Piston | Power Supply: | 3N-380V 50HZ |
| Theory: | Water Cooled | ||
| High Light: | Industrial Water Cooled Chiller, Box Type Industrial Water Cooled Chiller, High-Efficiency Industrial Water Cooled Chiller, Industrial Water Cooled Chiller AC-35WT, Industrial Water Cooled Chiller for Plastic Machine | ||
Quick Detail:1. High/Low pressure protection for the compressor and overheating protection inside the machine 2. Low water level alarm and low water temperature alarm 3. Certification:CE & ISO 4. Compressor type: Totally closed vortex type or piston type 5. Refrigerating capacity: 100869Kcal/h(50HZ) 6. Warranty:1 year | Description:1, Stainless plate, coil, shell and tube or fin type efficient heat exchanger 2, RS485 communication function, to realize automatic management(optional) 3, Electrical devices supplied from OMRON, FUJI, TE, LG, MOELLER and SCHNEIDER 4, Control mode: imported micro-computer or PLC(optional) 5, Perfect safety protection, failure display, and not requiring professional personnel for maintenance 6, Highly efficient evaporator and condenser, to save over 30% energy 7, 2 compressor heads for over AC-08, for individual or joint operation |
ITEM | UNIT | AC-35WT | |
Cooling capacity | KW50HZ | 117.28 | |
Kcal/h 50HZ | 100869 | ||
Total input | KW | 29.4 | |
Maximum Running Current | A | 65.4 | |
Power supply | 3N-380V 50HZ | ||
Refrigerant | Name | R22 | |
Charge | Kg | 6.2×3 | |
Control Type | External Balanced Thermostatic Expansion Valve | ||
Compressor | Type | Hermetic scroll or piston | |
Power | Kw | 9×3 | |
Cooling water | Flow | M3/h | 25.22 |
P.D. | Kpa | 37 | |
In/Out Pipe Size | G2-1/2” | ||
Chilled water | Flow | M3/h | 20.18 |
Tank | M3 | 0.405 | |
In/Out Pipe Size | G3” | ||
water Pump | Power | Kw | 4 |
Pressure | Kpa | 250 | |
Size(L×W×H) | mm | 2100×1020×2000 | |
Weight | Kg | 760 | |
High Cooling Capacity: With a massive 100869 Kcal/h capacity, this chiller ensures effective cooling for heavy-duty industrial processes.
Efficient Performance: Powered by advanced compressors and a reliable water pump, it provides optimal energy efficiency and consistent cooling.
Durability and Safety: Designed with a robust structure, this water cooled chiller incorporates safety features like pressure protection, ensuring long-lasting and secure operation.
Energy Efficient: The chiller’s high-performance design helps save energy, providing a more economical cooling solution for your operations.
Customizable Control: With external balanced thermostatic expansion valve control, this chiller offers precise and reliable temperature management.
Wide Applications: Perfect for industries like plastic injection molding, die casting, and other industrial cooling processes.
Plastic Injection Molding: Water cooled chillers maintain precise temperatures in plastic injection molding machines, ensuring high-quality, consistent products while improving cycle times and reducing defects.
Die Casting: In die casting, water cooled chillers provide efficient cooling to molds, enhancing product precision, reducing cycle time, and preventing overheating in high-temperature metal forming processes.
Chemical Processing: For chemical manufacturing, water cooled chillers regulate temperatures during reactions and distillation processes, ensuring safety, efficiency, and consistent output in controlled environments.
Rubber Tire Production: Water cooled chillers in tire production ensure optimal temperature control during vulcanization, improving product quality, reducing defects, and increasing production efficiency.
Metal Manufacturing: In metal manufacturing, water cooled chillers help maintain ideal temperatures in processes like welding and casting, promoting better material integrity, reducing distortion, and improving operational efficiency.
Advanced Technology: AODE uses cutting-edge technology to ensure maximum cooling efficiency and energy savings.
Proven Quality: With CE and ISO certifications, AODE’s chillers meet global standards, providing customers with trusted and reliable products.
Strong After-Sales Support: AODE provides expert customer service and reliable maintenance to ensure long-term performance.
Global Reach: AODE chillers are trusted by industrial businesses around the world for their high performance and durability.
The AC-35WT chiller provides a cooling capacity of 100869 Kcal/h (50Hz), making it ideal for large-scale industrial applications.
Yes, the AC-35WT is specifically designed for applications such as plastic injection molding, providing consistent and reliable cooling.
The AC-35WT uses R22 refrigerant, which is a common and effective choice for industrial water chillers.
The AC-35WT operates on a 3N-380V 50Hz power supply, suitable for industrial environments.
The chiller has a cooling water flow of 25.22 m³/h and a chilled water flow of 20.18 m³/h.
The AC-35WT is equipped with high/low pressure protection, overheating protection, and reliable alarm systems to ensure safe and stable operation.
