Product Details:
| Place of Origin: | Industrial Chiller Factory |
| Brand Name: | AODE |
| Certification: | ISO, CE, ROHS |
| Model Number: | AC-600WD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | $ |
| Packaging Details: | Protective/air bubble film, Wooden case. As client’s require |
| Delivery Time: | Within 20days after receiving |
| Payment Terms: | 30% T/T in advance, 70% balanc |
| Supply Ability: | 500pcs/month |
Plastic Rubber Water Cooled Water Chiller Systems With 516000 Kcal/h Capacity is a high-performance cooling solution designed for plastic, rubber, and chemical processing industries. Equipped with a semi-enclosed screw-type compressor, this chiller ensures stable and efficient cooling with a refrigerating capacity of 516,000 Kcal/h. Operating within a temperature range of 7-35°C, it maintains precision control at ±2°C, ensuring optimal performance for industrial applications. The unit is built with high-efficiency shell-and-tube evaporators and condensers, energy-saving components, and advanced control systems for reliable operation. Certified with CE & ISO, it features multiple safety protections, including high/low pressure switches, anti-icing alarms, and overload protection. Additionally, the RS485 communication function allows for automated system management, making it an ideal choice for large-scale cooling needs.
| Product Name: | Water Cooled Water Chiller Systems | Brand Name: | AODE |
|---|---|---|---|
| Application: | Rubber Presses|Chemical|Extruder | Certification: | CE|ISO |
| Compressor Type: | Semi-enclosed Screw-type | Power Input: | 122KW |
| Power Supply: | 3N-50HZ-380V | Temperature Range: | 7-35℃ |
| Theory: | Water Cooled | ||
| High Light: | Water Cooled Water Chiller Systems, Plastic Rubber Water Cooled Water Chiller Systems, Water Cooled Water Chiller Systems With 516000 Kcal/h Capacity | ||
ITEM | UNIT | AC-600WD | |
Refrigerating capacity | Kcal/h | 516000 | |
KW | 600 | ||
Input water | KW | 122 | |
Maximum Running Current | A | 206 | |
Energy adjust range | % | 100-75-50-25-0 | |
Power supply | 3N-50HZ-380V | ||
R22 Refrigerant | Filling Volume | kg | 50×2 |
Control mode | Thermostatic External valve | ||
Compressor | Model | Semi-enclosed screw-type | |
Power | Kw | 61×2 | |
Evaporator | Model | Shell and Tube | |
Chilled water flow | M3/h | 103.2 | |
Water resistance | Kpa | 46 | |
Water inlet/outlet diameter | DN | 125.0 | |
Condenser | Model | Shell and Tube | |
Chilled water flow | M3/h | 134.2 | |
Water resistance | Kpa | 49 | |
Water inlet/outlet diameter | DN | 125 | |
Protecting equipment | High/Low Pressure switch, Anti-frost Protector, Fusible Plug, Overload Protector, Motor Overheat Protector, Automatic Temperature Sensitive Switch, Anti-phase Protector | ||
Size(L×W×H) | mm | 3400×850×2000 | |
Weight | kg | 3150 | |
Running Weight | Kg | 3400 | |
High Cooling Efficiency – 516,000 Kcal/h capacity, suitable for high-demand industrial applications.
Precision Temperature Control – Maintains a stable 7-35°C range with ±2°C accuracy.
Energy-Saving Design – 30% energy savings with efficient evaporators and condensers.
Reliable Compressor – Semi-enclosed screw-type compressor for stable and powerful performance.
Advanced Control System – Micro-computer/PLC control with RS485 communication for automation.
Comprehensive Safety Protections – High/low pressure, anti-icing, overload, and overheat protection.
| Applications | Benefits |
|---|---|
| Plastic and Rubber Processing | Ensures stable cooling for injection molding, extrusion, and rubber presses. |
| Chemical and Industrial Processes | Maintains precise temperature control for chemical reactions and manufacturing. |
| Metal Processing | Supports casting, die-casting, and heat treatment cooling needs. |
| Electronics and Semiconductor Industry | Provides stable and reliable temperature regulation. |
| Food and Beverage Processing | Ensures consistent cooling for food production lines. |
| Medical and Pharmaceutical | Meets stringent temperature control requirements for medical applications. |
Custom Power Supply – Available in different voltage and frequency configurations.
Alternative Refrigerants – Options for eco-friendly refrigerants such as R134a or R407C.
Capacity Adjustments – Can be customized for different cooling loads as per industry needs.
PLC and Remote Monitoring – Integration with customized control systems for smart management.
Pump and Piping Customization – Upgraded pump options and inlet/outlet sizes to fit specific systems.
Material Customization – Special coatings and corrosion-resistant materials for harsh environments.
1. What is the cooling capacity of the Water Cooled Water Chiller System?
The AODE system provides a refrigerating capacity of 516,000 Kcal/h, making it suitable for high-load industrial applications.
2. What industries can benefit from using a Water Cooled Water Chiller System?
This chiller is ideal for plastic, rubber, chemical, food processing, metalworking, and electronics manufacturing industries.
3. How energy-efficient is the Water Cooled Water Chiller System?
It features high-efficiency shell-and-tube heat exchangers and optimized cooling mechanisms, reducing energy consumption by 30% compared to conventional systems.
4. What type of compressor does the Water Cooled Water Chiller System use?
It uses a semi-enclosed screw-type compressor, which ensures stable cooling, durability, and high energy efficiency.
5. Can the Water Cooled Water Chiller System be customized for different applications?
Yes, it offers customization in power supply, refrigerant type, control systems, pump specifications, and external coatings for different industrial needs.
6. What safety features are included in the Water Cooled Water Chiller System?
The unit comes with high/low pressure protection, anti-freeze protection, overload protection, motor overheating protection, and automatic fault detection for safe operation.
