Product Details:
| Place of Origin: | Air Chiler Manufacturer |
| Brand Name: | AODE |
| Certification: | ISO, CE, ROHS |
| Model Number: | AC-40AF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $ |
| Packaging Details: | Protective/air bubble film, Wooden case. As client’s require |
| Delivery Time: | Within 20days after receiving |
| Payment Terms: | 30% T/T in advance, 70% balanc |
| Supply Ability: | 500pcs/month |
113.58KW Modular Air Cooled Chiller Hermetic Scroll/Piston Compressor CE ISO Certified 3N-380V 50HZ is one type of our AODE's Modular Air Cooled Chiller, This Chiller is designed for high-performance cooling applications, delivering 113.58KW cooling capacity with hermetic scroll or piston compressors. Certified with CE & ISO, it ensures reliability with high/low pressure protection, overheating prevention, and low water level alarms. Featuring SUS304 stainless steel water tanks and Danfoss & Alco throttle components, this unit guarantees corrosion resistance and efficient operation. Ideal for die casting, injection molding, printing, chemical processing, and heat exchange systems, this chiller excels in industries requiring stable temperature control. With customization options such as thick copper pipes (1.0-1.2mm) and branded electrical components (OMRON, ABB, LG), it is a long-term, cost-effective cooling solution backed by nationwide technical support and a 1-year warranty.
| Product Name: | Modular Air Cooled Chiller | Brand Name: | AODE |
|---|---|---|---|
| Application: | Die Casting|Pringting|Chemical | Certification: | CE|ISO |
| Compressor Type: | Hermetic Scroll Or Piston | Power Supply: | 3N-380V 50HZ |
| Theory: | Air Cooled | ||
| High Light: | Modular Air Cooled Chiller, 113.58KW Modular Air Cooled Chiller, Modular Air Cooled Chiller Hermetic Scroll/Piston Compressor, Modular Air Cooled Chiller CE ISO Certified, 3N-380V 50HZ Modular Air Cooled Chiller | ||
ITEM | UNIT | AC-40AF | |
Cooling capacity | KW50HZ | 113.58 | |
Kcal/h 50HZ | 97675 | ||
Total input | KW | 42.8 | |
Maximum Running Current | A | 97.5 | |
Power supply | 3N-380V 50HZ | ||
Refrigerant | Name | R22 | |
Charge | Kg | 8.5×4 | |
Control Type | External Balanced Thermal Expansion Valve | ||
Compressor | Type | Hermetic Scroll or Piston | |
Power | Kw | 7.5×4 | |
Air Flow | M3/h | 40000 | |
Chilled water | Flow | M3/h | 19.53 |
Tank | M3 | 0.61 | |
In/Out Pipe Size | G3” | ||
water Pump | Power | Kw | 4 |
Pressure | Kpa | 250 | |
Size(L×W×H) | mm | 2565×1220×2310 | |
Weight | Kg | 1100 | |
High Cooling Capacity – Provides 113.58KW (97675Kcal/h at 50HZ) cooling power, ensuring efficient temperature control for industrial applications.
Premium Compressor – Equipped with hermetic scroll or piston compressors, delivering high efficiency, energy savings, and long-term reliability.
Advanced Safety Protection – Includes high/low-pressure protection, overheating protection, low water level alarm, and low water temperature alarm, ensuring safe operation.
High-Quality Components – Features a SUS304 stainless steel water tank for corrosion resistance and Danfoss (Denmark) and Alco (US) throttle components for superior performance.
Applications:This Modular Air Cooled Chiller is widely used in industries requiring precise cooling, including:
| Customization:
|
Best Investment Scenarios:113.58KW Modular Air Cooled Chiller is the best choice when:
| Technical Support & After-Sales Service:
|
What is the cooling capacity of this chiller?
It delivers 113.58KW (97675Kcal/h at 50HZ) cooling capacity, suitable for industrial applications.
What type of compressor does this chiller use?
It features hermetic scroll or piston compressors for high efficiency and durability.
Is this chiller suitable for high-temperature environments?
Yes, it is equipped with overheating protection, high/low pressure safety features, and insulated components.
Can the chiller be customized for specific industrial applications?
Yes, it supports custom copper piping (1.0-1.2mm) and high-density heat insulation for specific needs.
What industries benefit most from this chiller?
It is ideal for die casting, plastic injection molding, printing, chemical processing, and heat exchangers.
What kind of after-sales support is provided?
We offer nationwide service support, technical assistance, and a 1-year product warranty.
Address: No.37,Dayang Industrial Area, Xingang East Road, Lougang Boulevard, Songgang Town, Bao'an District, Shenzhen
